Source : hilbert01.mp

hilbert01.mp
input tortue.mp;
numeric d,iter;

vardef trace(expr a,b) = draw a--b enddef;

vardef L(expr n,m) =
if m>0:
 tourne(n,90);
 R(n,m-1);
 avance(n,d,trace);
 tourne(n,-90);
 L(n,m-1);
 avance(n,d,trace);
 L(n,m-1);
 tourne(n,-90);
 avance(n,d,trace);
 R(n,m-1);
 tourne(n,90);
fi
enddef;

vardef R(expr n,m) =
if m>0:
 tourne(n,-90);
 L(n,m-1);
 avance(n,d,trace);
 tourne(n,90);
 R(n,m-1);
 avance(n,d,trace);
 R(n,m-1);
 tourne(n,90);
 avance(n,d,trace);
 L(n,m-1);
 tourne(n,-90);
fi
enddef;

hilbert01.mp (figure 1)
beginfig(1);
iter := 1;
d := 8cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

hilbert01.mp (figure 2)
beginfig(2);
iter := 2;
d := 4cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

hilbert01.mp (figure 3)
beginfig(3);
iter := 3;
d := 2cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

hilbert01.mp (figure 4)
beginfig(4);
iter := 4;
d := 1cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

hilbert01.mp (figure 5)
beginfig(5);
iter := 5;
d := .5cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

hilbert01.mp (figure 6)
beginfig(6);
iter := 6;
d := .25cm;
tortue(1,0,0,90,1);
L(1,iter);
endfig;

end
