Album Pop'art

popart.mp [ source brut ]

 input geometriesyr16;

 vardef popart(expr deg,div,rep,sens,coul,coull)=
   save $;
   picture $;
   save T;
   transform P[];
   path cc;
   cc=cercles(u*(10,10),10u);
   pair sommet[];
   marque_p:="plein";
   sommet0=pointarc(cc,0);
   for k=1 upto deg:
     sommet[k]=rotation(sommet[k-1],u*(10,10),360/deg);
     pointe(sommet[k]);
   endfor;
   pair A,B,C;
   A=u*(10,10);
   for k=0 upto (deg-1):
     B:=sommet[k];
     C:=sommet[k+1];
     if sens=-1:
       if (k mod 2)=0:
 	A transformed P[k]=(1/div)[A,B];
 	B transformed P[k]=(1/div)[B,C];
 	C transformed P[k]=(1/div)[C,A];
       else:
 	A transformed P[k]=((div-1)/div)[A,B];
 	B transformed P[k]=((div-1)/div)[B,C];
 	C transformed P[k]=((div-1)/div)[C,A];
       fi
     else:
       A transformed P[k]=(1/div)[A,B];
       B transformed P[k]=(1/div)[B,C];
       C transformed P[k]=(1/div)[C,A];
     fi;
   endfor;
   $=image(
     for k=1 upto deg:
       B:=sommet[k-1];
       C:=sommet[k];
       picture dessin;
       if (k mod 2)=1:
 	dessin=image(
 	  fill A--B--C--cycle withcolor coul;
 	  fill ((A--B--C--cycle) transformed P[k-1]) withcolor coull;
 	  trace A--B--C--cycle;
 	  trace ((A--B--C--cycle) transformed P[k-1]);
 	  );
 	trace dessin;
 	for j=1 upto (rep/2):
 	  dessin:=dessin transformed (P[k-1]) transformed (P[k-1]);
 	  trace dessin;
 	endfor;
       else:
 	dessin=image(
 	  fill A--C--B--cycle withcolor coul;
 	  fill ((A--C--B--cycle) transformed P[k-1]) withcolor coull;
 	  trace A--C--B--cycle;
 	  trace ((A--C--B--cycle) transformed P[k-1]);
 	  );
 	trace dessin;
 	for j=1 upto (rep/2):
 	  dessin:=dessin transformed P[k-1] transformed P[k-1];
 	  trace dessin;
 	endfor;
       fi;
     endfor;
     );
   $
 enddef;
 u:=7.5mm;

Conversion au format PDF de popart.1
 beginfig(1);
 %figure(0,0,20u,20u);
 trace popart(6,10,30,-1,blanc,blanc);
 %fin;
 endfig;

Conversion au format PDF de popart.2
 beginfig(2);
 %figure(0,0,20u,20u);
 trace popart(12,15,20,-1,blanc,blanc);
 %fin;
 endfig;

Conversion au format PDF de popart.3
 beginfig(3);
 %figure(0,0,20u,20u);
 trace popart(12,15,20,1,blanc,blanc);
 %fin;
 endfig;

Conversion au format PDF de popart.4
 beginfig(4);
 %figure(0,0,20u,20u);
 trace popart(16,15,20,-1,blanc,blanc);
 %fin;
 endfig;

Conversion au format PDF de popart.5
 beginfig(5);
 %figure(0,0,20u,20u);
 trace popart(16,15,20,1,blanc,blanc);
 %fin;
 endfig;

Conversion au format PDF de popart.6
 beginfig(6);
 %figure(0,0,20u,20u);
 trace popart(6,10,30,1,jaune,violet);
 %fin;
 endfig;

Conversion au format PDF de popart.7
 beginfig(7);
 %figure(0,0,20u,20u);
 trace popart(12,15,20,1,jaune,3/5[jaune,blanc]);
 %fin;
 endfig;
 end
